MSW-21C-WL4C

MSW 防塵防水微動開關(彈片式)

MSW series proof and Waterproof Micro Switch (Leaf Spring Type)

產品描述Product description

◆MSW系列是一款專用型的微動開關，裝上防護罩后具有防塵防水性能，適用于各類手持電動工具和園林工具，如：砂光機、拋光機、小角磨、電動噴槍、打草機、電鏈鋸、吹吸機等。
◆MSW?series are special type micro switches, with?Protection?Cap?for?dustproof?and?waterproof, commonly for used in portable power-tools and gardening tools, such as Sanders, Polisher Grinders, Electric Sprayers, Small Angle Grinders， Grass Trimmers, Electric Chain Saws, Blowers, etc.

產品特征Features

◆可選附帶以下功能 Optional with the function as follows:
→單極常開 SPNO (Single Pole Normally Open)
→單極常閉 SPNC (Single Pole Normally Close)
→單極常閉常開 SPCO (Single Pole Close and Open)
→雙極常開 DPNO (Double Pole Normally Open)
→雙極常閉 SPNC (Double Pole Normally Close)
→雙極常閉常開 SPCO (Double Pole Close and Open)
→一極常開，另一極常閉One Pole NO, the Other NC
→一極常開，另一極常閉常開One Pole NO, the Other CO
◆可選附帶以下附件 Optional with the accessories as follows:
→壓柄 Push Handle
→防護罩 Protection Cap
→焊接帶端子導線 Soldering with leads and terminals

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥5E4/1E5
→電氣耐久壽命 Electrical life endurance≥1E4/ 5E4
→最大沖擊電流 Max. Inrush current at 250V60A
→最大沖擊電流 Max. Inrush current at 127V96A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M  Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature (ENEC/UL)-20°C~125°C
→環境溫度 Ambient temperature (TüV/CQC)0°C~85°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP67 MAX.
→適用于II類防護器具 Suitable for appliances of protection class II
→開關操作力選擇范圍 Operating forcer ange3N~15N
→開關內部觸點間隙 Contact gap range1.0~2.5mm

端子類型Terminals

◆COM, NO, NC端子 Terminals:
→插片端子 Plug-in terminals 4.8×0.8mm
→插片端子 Plug-in terminals 4.8×0.5mm
→焊接端子 Solder terminals
→外接導線端子 Wires terminals
★本產品榮獲實用新型專利，專利號：ZL201821286857.4
★Utility Model patented with the no. is?ZL201821286857.4

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
