產品描述Product description
◆Mk16系列是一款專用型交流轉盤線路板組件，具有軟啟動等功能，廣泛應用于各類手持式電動工具，如：150和180角向磨光機、往復鋸等。
◆MK16 series are one special type AC PCB Assembly with dial wheel, integrated soft start function, etc. Commonly for used in portable power-tools such as 150mm and 180mm Angle Grinders, Reciprocating Saws, etc.
產品特征Features
◆可選帶以下功能 Optional following function types:
→電子調速功能 Electronics Speed Control(E)
→斷電重啟保護功能 Restart Protection(X)
→軟啟動功能 Soft Start Function(S)
→過流保護功能 Over Current Protection Function(CP)
→過溫保護功能 Over Temperature Protection Function(TP)
技術數(shù)據(jù)Technical data
→電氣耐久壽命 Electrical life endurance≥5E4
→最大電流 Max. current at 250V15A
→最大電流 Max. current at 127V24A
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Dielectric strength of reinforced3000V
→環(huán)境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→導線端子 Wire lead terminals
電氣參數(shù)和認證 Electric Rating and Certification
