FA7-6B-2L16

FA7-6B防塵按鈕開關

FA7-6B series Dustproof Push-button Switches

產品描述Product description

◆FA7-6B系列是一款專用型的按鈕開關，集成防塵功能，應用于各類手持式電動工具，如：電木銑、修邊機等，可選帶閉合自鎖功能。
◆FA7-6B series are special type Push-button switch, integrated dustproof, popular for used in portable power-tools such as Electric Routers, etc. Optional with self-lock function.

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V60A
→最大沖擊電流 Max. Inrush current at 125V96A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M  Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端 Input side:
→接線柱端子 Pillar terminals φ=3mm
◆輸出端 Output side:
→接線柱端子 Pillar terminals φ=3mm

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
