◆可選帶以下功能 Optional with following function:
→雙極單擲 DPST (Double Pole Single Throw)
→雙極雙擲 DPDT (Double Pole Double Throw)

→雙極雙擲帶中間斷開 DPDT with center off

→點動方式 Momentary act

→機械耐久壽命 Mechanical life endurance≥5E4/1E5
→電氣耐久壽命 Electrical life endurance≥1E4/5E4
→最大沖擊電流 Max. Inrush current at 250V60A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Diele ctric strength of reinforced3000V
→環(huán)境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection type IP40
→適用于II類防護器具 Suitable for appliances of protection class II

◆輸入端/輸出端 Input side/Output side:
→接線柱端子 Pillar terminals φ=3.5mm
